Placa de baza MSI MEG Z490I UNIFY, Socket 1200
Produse asemanatoare
Placa de baza MSI MEG Z490i UNIFY LGA 1200 911-7C77-008 / 4719072720186 SPECIFICATION Model Name MEG Z490I UNIFY CPU Support Supports 10th Gen Intel® Core™ and Pentium® Gold / Celeron® processors CPU Socket LGA 1200 Chipset Intel® Z490 Chipset Graphics Interface 1x PCI-E 3.0 x16 slot Display Interface Thunderbolt™ 3 (Type-C), DisplayPort port 1.4, HDMI – Requires Processor Graphics Memory Support 2 DIMMs, Dual Channel DDR4-5000MHz(OC) Storage 2 x Turbo M.2 32Gb/s slots, supports Intel® Optane™ technology 4x SATA 6Gb/s USB ports 3 x USB 3.2 Gen 2 10Gbps (1 Type-A + 2 Type-C) + 4 x USB 3.2 Gen 1 5Gbps (Type-A) + 4 x USB 2.0 LAN Realtek® 8125B 2.5G LAN WiFi / BT Intel® Wi-Fi 6 AX201, Bluetooth 5.1 Audio 8-Channel(7.1) HD Audio with Audio Boost 4 Form Factor Mini-ITX https://www.msi.com/Motherboard/MEG-Z490I-UNIFY/Specification
| Caracteristici Placa de baza MSI MEG Z490I UNIFY, Socket 1200: | |
| CPU Socket | 1200 |
| Chipset | Z490 |
| Procesoare suportate | 10th Gen Intel Core, 11th Gen Intel Core, Pentium Gold and Celeron processors |
| Memorii suportate | DDR4 |
| Sloturi memorie | 2 |
| Suport Dualchannel | Da |
| Frecventa memorie (MHz) | 2933/2666/2133 |
| Video integrat | Da |
| Slot video | PCI Express |
| Tip video integrat | Necesita procesor cu tehnologia Intel HD Graphics |
| Audio integrat | Realtek ALC1220 |
| LAN integrat | Realtek RTL8125B |
| Interfata Serial ATA | 4 x SATA III |
| RAID integrat | 0, 1, 5, 10 |
| Tip port USB 3.1/3.2 | Type-A |
| Porturi USB 3.0 | 3 |
| Porturi USB 2.0 | 2 |
| HDMI | 1 |
| VGA | Nu |
| DVI | Nu |
| DisplayPort | DP |
| Porturi externe | Optical S/PDIF Out, RJ45, Audio |
| Sloturi PCI-E x16 | 1 |
| Sloturi M.2 | 2 |
| Format | Mini ITX |
| Dimensiuni (L x l, cm) | 17 x 17 |
| Greutate Colet | 1 |
| Placa de baza MSI MEG Z490I UNIFY, Socket 1200 | |
| CPU Socket | 1200 |
| Chipset | Z490 |
| Procesoare suportate | 10th Gen Intel Core, 11th Gen Intel Core, Pentium Gold and Celeron processors |
| Memorii suportate | DDR4 |
| Sloturi memorie | 2 |
| Suport Dualchannel | Da |
| Frecventa memorie (MHz) | 2933/2666/2133 |
| Video integrat | Da |
| Slot video | PCI Express |
| Tip video integrat | Necesita procesor cu tehnologia Intel HD Graphics |
| Audio integrat | Realtek ALC1220 |
| LAN integrat | Realtek RTL8125B |
| Interfata Serial ATA | 4 x SATA III |
| RAID integrat | 0, 1, 5, 10 |
| Tip port USB 3.1/3.2 | Type-A |
| Porturi USB 3.0 | 3 |
| Porturi USB 2.0 | 2 |
| HDMI | 1 |
| VGA | Nu |
| DVI | Nu |
| DisplayPort | DP |
| Porturi externe | Optical S/PDIF Out, RJ45, Audio |
| Sloturi PCI-E x16 | 1 |
| Sloturi M.2 | 2 |
| Format | Mini ITX |
| Dimensiuni (L x l, cm) | 17 x 17 |
| Greutate Colet | 1 |
